The textile waste cutting machine is a specialized device for processing waste textile materials. It can cut textile waste (such as used clothes, fabric scraps, textile waste filaments, etc.) as needed, facilitating subsequent recycling and utilization.
This type of cutting machine is a rotary rotary knife cutting machine and has the following advantages:
High cutting efficiency (over 2000 shearing times per minute)
2. High length accuracy, adjustable shearing thickness from 1 to 100mm and length from 5 to 150mm
The tool head can hold 1 to 10 cutting tools, with a cutting edge of 400 to 800mm
4. It is suitable for various soft materials (waste cloth, old clothing, cotton wadding, etc.). By changing the conveying speed, the cutting specifications can be adjusted to flexibly meet different needs
Product Characteristics
1，the tool design is reasonable: the use of special alloy steel tools, high strength, good wear resistance. The fixed tool can be adjusted to maintain the gap with the moving tool to ensure a good crushing effect.
2，the crushing capacity is strong: with efficient shredding capacity, can provide large shear force, can handle different materials, thickness of plastic film, high output.
3，high degree of automation: equipped with PLC automatic control system to achieve automatic control, with start, stop, reverse and overload automatic reversal functions.
4，safety and environmental protection: with electronic control safety design, some models of the hopper adopts a double-layer structure, filled with sound insulation materials, can reduce noise.
5，easy maintenance: reducer with rubber vibration protection transmission parts, screen access door is easy to replace, easy to maintain and maintain.
Product application direction
Waste fiber cutting machine is used to cut all kinds of fibers, such as chemical fiber, breast fiber, glass fiber, all kinds of textiles, old cloth and all kinds of waste yarn, cutting waste cloth, waste cloth, denim, waste clothes, sponge, glass fiber, hemp fiber, chemical fiber, cloth, nylon cloth, PET fiber, fishing net, nylon net, PP rope, film, woven bags and other soft materials, etc. After cutting them into small pieces, they can be recycled. The tool adopts low speed large torque motor, the transmission process adopts cycloidal pin wheel reducer, speed regulation frequency conversion speed regulation, the operation and maintenance of each component is convenient. It has durable, stable and safe performance, which can improve production efficiency.
Product Parameters
Basic Info.
| Model number | MT800 | MT1200 | MT1600 | MT2400 | MT3200 |
| Main motor | 8P7.5kw | 8P15kw | 8P18.5kw | 8P15kw(Two sets) | 8P30kw(Two sets) |
| Conveyer motor | 4p1.5kw | 4p2.2kw(Variable frequency motor) | 4p3.0kw(Variable frequency motor) | 4p4.0kw(Variable frequency motor) | 4p5.5kw(Variable frequency motor) |
| Belt wheel | Φ100 | Φ140 | Φ120 | Φ140 | Φ350 |
| Moving blade base | Φ300 | Φ400*600 | Φ500*800 | Φ600*1200 | Φ1000*1500 |
| Feeding conveyor | 1400*330mm | 3000*520mm | 3000*720mm | 3000*1100mm | 3000*1400mm |
| Output conveyor | 1400*330mm | 3000*520mm | 3000*720mm | 3000*1100mm | 3000*1400mm |
| Machine size | 2100*1000*1100 | 1400*1450*1500 | 1550*1700*1550 | 2100*1900*1550 | 3000*3300*3000 |
| Cutting size | 2.5.8CM | tunable | tunable | tunable | tunable |
| Capacity | 500-800kg/h | 800-1200kg/h | 1500-1200kg/h | 3000-4000kg/h | 6000-8000kg/h |
