Morinte high wear-resistant textile recycling specialized needle cloth is the core working component for industrial waste recycling machinery. By utilizing precision mechanical force, it efficiently loosens, cards, and removes impurities from waste fabrics, garment clips, and yarn waste. It tears and transforms tangled raw materials into premium single fibers, preparing them perfectly for subsequent textile spinning and nonwoven fabric reuse.
Exteded Wear Life (HRC60+ Rating): Features a hidden martensite structure with a tooth tip hardness of HRC60+. It handles 30%+ more material than ordinary wire clothing, drastically reducing machine downtime and replacement frequency.
High Resistance to Tooth Breakage: Engineered wih a hard tooth tip combined with a tough, tempered troostite tooth body. When encountering accidental metal debris, the teeth deform rather than snap, preventing catastrophic machine jamming and production stoppage.
High-Uniformity Precision Carding: The tooth profile precision is strictly controlled within ±0.02mm (fully meeting the GB/T 24377 national standard). Opening, carding, and impurity removal are achieved in one single step, ensuring stable recycled fiber length.
Long-Lasting Straightness & Collapse Resistance: Utilizing a 70# high-carbon steel base combined with elastic recovery heat treatment. It maintains a perfectly straight tooth profile even under ultra-high-speed operation for sustained factory efficiency.
Convenient & Hassle-Free Installation: Designed with a flat base edge without waves, ensuring smooth wrapping without curling. Two workers can complete the installation within two hours, saving costly labor and maintenance time.
Metallic wire clothing is the "Heart & Teeth" of your entire textile recycling machine.
While feeding and conveying systems are auxiliary, only the card clothing directly performs the core tasks: Opening, Carding, and Impurity Removal.
High-Quality Wire = High-Value Fibers: Uniform carding minimizes fiber damage, resulting in longer, high-purity recycled fibers that sell at a premium price for ring spinning and high-end nonwovens.The performance ceiling of your wire clothing defines the production capacity ceiling of your entire recycling plant.
Custom dimensions and tooth profiles are available upon request to fit any cylinder or doffer roller.)
Model | Height (mm) | Angle | Number of teeth | Tooth thickness |
5610*36109 | 5.6 | 10 | 3.6 | 1.09 |
5610*42109 | 5.6 | 10 | 4.2 | 1.09 |
5610*56109 | 5.6 | 10 | 5.6 | 1.09 |
8515*72150 | 8.5 | 15 | 7.2 | 1.5 |
9510*73120 | 9.5 | 10 | 7.3 | 1.2 |
9110*7320 | 9.1 | 10 | 7.3 | 2.0 |
We manufacture premium metallic card clothing for a wide range of textile machinery:
Cotton Mills: Metallic card clothing and stationary flats for flat carding machines.
Worsted & Woolen Mills: Interlocking and chain card clothing for roller cards.
Nonwoven Factories: High-speed card clothing for web-forming thermal bonding and needle punch lines.
Waste Recycling Sectors: Specialized wire for clothing/shredding/rag tearing machines (Models: 9110-7320, 5610-42109, etc.).
Advanced R&D and Manufacturing Base: Our Chinese factory integrates an elite R&D team and highly disciplined management. Our production lines undergo continuous technological upgrades to ensure world-class metallic wire consistency.
Frontier Industry Insights: Our engineers regularly participate in international textile machinery exhibitions (such as ITMA). We constantly innovate our tooth shapes based on the evolving trends of global textile recycling.
Proven Global Track Record: We serve a massive network of end-users worldwide. Through close feedback loops with global spinning mills, our product designs are continuously perfected for real-world scenarios.
Local Technical Support (Pakistan & Bangladesh): We eliminate overseas maintenance worries. With dedicated, localized installation and technical support teams in Pakistan and Bangladesh, on-site assistance is just a phone call away, saving your valuable production time.
Q: How do I maintain the metallic wire to extend its service life?
A: We highly recommend installing a magnetic metal detector at the feeding inlet to filter out metallic impurities. Regularly check for loose pins, and ensure no hard stones or foreign objects enter the tearing cylinders.
Q: Can your card clothing be replaced on-site by our team?
A: Yes. The structure features a standardized base for easy wrapping. We provide step-by-step instructional videos, and remote video technical guidance is always available for our global clients.
Q: What is the typical lead time for international orders?
A: Standard metallic wire models can be shipped within 15–30 days. Fully customized tooth profiles or bulk OEM orders generally require 30–45 days.
Q: Do you offer customized wire dimensions for different cylinder diameters?
A: Absolutely. We can customize the width, height, angle, and feet configuration according to your specific machinery blueprints.
Q: What documents do you provide for customs clearance and export?
A: We provide a full standard export documentation package, including Commercial Invoice, Packing List, Bill of Lading, Certificate of Origin (CO/Form E), and COC upon request.
Q: How can I request a quote or place an order?
A: Please send your required models or roller specifications to our sales email or call us directly. Our engineering team will provide a detailed technical quote within 24 hours.
